- DIY Supplies: ELECTRICAL
- Certification: CE
- Origin: Mainland China
- Model Number: RF-4KC1
- is_customized: No
- Package: Case
- Type: HD CAMERA
- Application: Computer Tool Kit
- Pixel: 8.0mp
- Frame Rate: 30 fps
- output: HD/USB
- Application: Industry Education Laboratory
- storage: USB disk,capacity<=64GB
Specification
|
The parameter types
|
The parameter value
|
|
Sensor Target surface size
|
1/2.8″
|
|
The sensor resolution
|
4k/3840*2160@30fps
|
|
Output interface
|
HDMI 4k@30fps
|
|
Mode of operation
|
button
|
|
Working voltage
|
DC 12V
|
|
Storage
|
Usb disk, capacity<=64GB
|
|
The lens type
|
Supports C/CS interfaces
|
|
Photograph
|
8 million, JPG
|
|
Video
|
3840*2160 avi
|
|
Cross curve
|
8*8 groups
|
|
File Manager
|
With
|
|
Parameter type
|
specific parameter
|
Tip:
Hold down the ‘1080 key’ for 10 seconds to 1080P resolution
Hold down the ‘4K key’ for 10 seconds to switch to 4K resolution
Install and use
1. The microscope is connected to the host computer through C/CS interface, and tightened to prevent falling;
2. HDMI connection to monitor. Display should support 3840*2160/1920*1080 resolution;
3. Use USB interface to connect computer for UVC camera;
4. Connect the power adapter to the host through the DC port.
5. The TF card can be used with related functions: taking photos, video recording, playback, etc. If necessary, please insert it;
6.Switch on the power adapter, and the host indicator shows green for 10 seconds.
